The sandwich structure of tungsten disulfide is a vivid description of its hexagonal layered structure and has unique atomic composition, interlayer interaction, and rich derivative properties.
From the perspective of atomic composition, the sandwich structure consists of three layers of atoms, with a tungsten atom layer in the middle and two sulfur atom layers on the top and bottom. In this structure, each tungsten atom forms an octahedral coordination structure with six sulfur atoms from the upper and lower layers. Specifically, the tungsten atom is located at the center of the octahedron, and the six surrounding sulfur atoms come from the upper and lower layers and are evenly distributed at the vertex positions of the octahedron. This atomic arrangement repeats continuously in the two-dimensional plane, forming a stable planar structure. Each such three-layer atomic combination constitutes a basic unit, and numerous basic units are orderly arranged in the plane to construct the two-dimensional layered structure of tungsten disulfide.
The interlayer interaction plays a crucial role in the sandwich structure. The tungsten-sulfur atoms within the layer are closely connected by covalent bonds. The formation of covalent bonds is due to the overlap of atomic orbitals, and the electron cloud is shared between atoms, which has a relatively high bond energy and ensures the stability and strength of the structure within the layer. Between layers, that is, between different three-layer atomic combinations in the sandwich structure, they are stacked together by van der Waals forces. Van der Waals forces are a kind of weak intermolecular force, and its strength is much lower than that of covalent bonds. This weak interaction allows the layers to slide relative to each other, which is the fundamental reason for the good lubricating performance of tungsten disulfide. In practical applications, when tungsten disulfide is used as a lubricant, during the friction process of mechanical components, the layers in the sandwich structure can move relative to each other easily, effectively reducing the friction coefficient, energy consumption, and component wear.
The sandwich structure also derives many unique properties. In terms of electrical properties, since the covalent bonds within the layer are conducive to the transmission of electrons in the plane, electrons can move relatively freely within the layer, making tungsten disulfide have a certain electrical conductivity in the direction parallel to the layer plane. In the direction perpendicular to the layer plane, electron transmission is hindered by van der Waals forces, and the electrical conductivity is poor, showing obvious electrical anisotropy. In terms of optical properties, this sandwich structure has an impact on the absorption, scattering, and emission characteristics of light. The arrangement of atoms and the distribution of the electron cloud within the layer determine its absorption and response to light of specific wavelengths, and the interaction between layers will also affect the propagation of light between layers. In addition, the sandwich structure enables tungsten disulfide to have the possibility of intercalation reactions with some substances. Due to the weak van der Waals forces between the layers, some small molecules or ions can intercalate into the interlayer, changing the interlayer spacing and thus affecting its electrical, optical, and mechanical properties. For example, lithium ions and other ions can intercalate into the interlayer of tungsten disulfide. In battery electrode materials, this intercalation reaction will change the electronic structure of tungsten disulfide and affect its charge-discharge performance, providing a basis for its application in the field of energy storage.
