Molybdenum crucibles are mainly based on their manufacturing process, purpose, shape, size, material composition and surface treatment. The following are common classification methods:
- Classification by manufacturing process
Sintered molybdenum crucible:
It is made by pressing molybdenum powder into a shape through powder metallurgy process and then sintering it at high temperature.
Features: Low cost, suitable for mass production, but slightly lower density (~90-95% theoretical density), slightly inferior strength and durability.
Application: general high temperature melting or sintering process.
Forged molybdenum crucible:
from molybdenum billet through forging, turning and other mechanical processing.
Features: high density (close to 100% theoretical density), excellent mechanical strength and high temperature resistance, and high surface finish.
Application: High-precision processes such as semiconductor crystal growth and precious metal smelting.
Spinning molybdenum crucible:
The molybdenum sheet is processed into the crucible shape through the spinning process.
Features: Uniform wall thickness, suitable for thin-walled crucibles, moderate cost, but limited in size.
Application: small and medium-sized high temperature experiments or specific industrial applications.
Welding molybdenum crucible:
of welded molybdenum plates or sheets, it is suitable for complex shapes or large crucibles.
Features: High flexibility, but welds may affect high temperature performance.
Application: Special shape or large size requirements.
- Classification by material composition
Pure molybdenum crucible:
of high purity molybdenum (more than 99.95%).
Features: Good chemical stability, high temperature resistance (up to ~2000°C in vacuum), but poor oxidation resistance.
Application: High temperature processes under vacuum or inert atmosphere.
Molybdenum alloy crucible:
Doped with a small number of elements (such as tungsten, lanthanum, rhenium) or made into molybdenum -based alloys (such as Mo-W, Mo-La).
Features: Improved creep resistance, strength and oxidation resistance, but higher cost.
Application: Extremely high temperature or high mechanical stress environment.
- Classification by purpose
Crucible for metallurgy:
Used for smelting rare metals (such as tungsten and tantalum), precious metals (such as gold and silver) or alloys.
Features: High temperature resistance, corrosion resistance, and compatibility with molten materials.
Crucible for semiconductor:
Used for single crystal silicon, sapphire crystal growth or thin film deposition.
Features: high purity, smooth surface, high dimensional accuracy.
Crucibles for glass/ceramics:
Used for melting special glass or sintering high-temperature ceramics.
Features: Resistant to high temperature chemical corrosion, must avoid reaction with certain oxides.
Laboratory Crucibles:
Used for high temperature experiments, heat treatment or material testing in scientific research.
Features: Various sizes, suitable for various experimental conditions.
- Sort by shape
Cylindrical crucible: the most common, suitable for most melting and heat treatment processes.
Conical crucible: convenient for material pouring or specific crystal growth process.
Rectangular/square crucible: used for special processes or large equipment.
Custom Shapes: Customized to meet specific needs such as complex geometries.
- Sort by size
Small crucible: capacity ranges from a few milliliters to several hundred milliliters, suitable for laboratories or small-scale production.
Medium crucible: capacity ranges from several hundred milliliters to several liters, used in industry or scientific research.
Large crucible: with a capacity of more than tens of liters, used for large-scale metallurgy or semiconductor production.
- Classification by surface treatment
Polished crucible: The surface is polished to have high smoothness, reduce material adhesion, and is suitable for high-purity processes.
Coated crucible: The surface is coated with an anti-oxidation or anti-corrosion coating (such as alumina, silicide) to improve durability.
Untreated crucible: directly processed into shape, low cost, suitable for general use.
======================================================================
