Forging is suitable for high-precision, high-strength crucibles, commonly used in semiconductor and precious metal smelting.
step:
Raw material preparation
Select molybdenum billet: Use high-purity molybdenum rods or molybdenum plates (purity ≥ 99.95%), which are made by powder metallurgy sintering and forging/rolling, and the density is close to the theoretical value.
Quality control: Check the chemical composition, density and internal defects (such as cracks and inclusions) of the blank.
Pretreatment of blanks
Cutting: Cut molybdenum rods or plates into sizes suitable for processing.
Heating: Preheat the blank in an inert atmosphere or vacuum furnace at 1200-1500°C to increase ductility and reduce work hardening.
Forging or machining
shaped into the shape of a crucible through forging, extrusion or rotary forging.
Finishing: Use CNC lathes, milling machines or grinders to precisely process the inner and outer surfaces, wall thickness and bottom of the crucible to ensure high dimensional accuracy.
Process environment: Oxidation should be avoided during processing and it should be carried out under inert atmosphere if necessary.
Heat treatment (annealing)
Annealing at 800-1200°C in vacuum or hydrogen atmosphere for 1-2 hours can eliminate processing stress, improve crystal structure and enhance toughness.
Cool slowly to avoid thermal stress.
Surface treatment
Polishing: Mechanically or chemically polish the inner surface to improve finish and corrosion resistance.
Coating (optional): Apply an anti-oxidation coating (such as ZrO ₂) to extend high temperature life.
Cleaning: Use pickling or ultrasonic cleaning to remove impurities such as oil, oxides, etc.
Quality Inspection
Dimensions and Appearance: Check the crucible dimensions, surface finish and geometry.
Performance tests: Density (~10.2 g/cm³), hardness, microstructure and impurity content.
Nondestructive testing: Use ultrasound or X-rays to check for internal defects.
High temperature simulation (optional): Verify the mechanical and chemical stability of the crucible at high temperatures.
Packaging and storage
Same as sintered crucible, in anti-oxidation packaging, stored in a dry environment.
======================================================================
