How to Prolong the Service Life of Molybdenum Crucible?

Extending the service life of molybdenum crucibles lies in the correct operating environment, reasonable heating method, prevention of chemical corrosion and daily maintenance. Although molybdenum itself has a high melting point (2620°C), high strength and good thermal shock resistance, it is easy to oxidize, embrittle or react with certain substances at high temperatures, so special attention should be paid to the following points:

  1. Control the use environment

Avoid oxidation

Molybdenum begins to oxidize strongly above 600°C in air, forming volatile MoO₃. Therefore:

When used at high temperatures, it must be heated in a vacuum or inert atmosphere (such as argon or helium).

Never heat directly in air

Control water vapor and acid-base gases

Avoid contact with gases such as H₂O, HCl, H₂SO₄, NOₓ, etc., and be especially careful when heating aqueous samples.

  1. Optimize the heating and cooling procedures

Slowly warm up

Prevent internal stress cracking of materials caused by thermal shock;

It is recommended to use a step-by-step heating method (e.g., 5–10°C per minute) for initial use or after annealing.

Progressive Cooling

Do not move out of the high temperature area immediately after use, but cool slowly in the furnace to reduce the risk of thermal stress.

  1. Regular heat treatment and annealing

After repeated use, molybdenum may become brittle due to stress concentration. It is recommended that:

Periodically perform high temperature annealing (e.g. 1000–1200°C for 1 hour in vacuum or argon) to release internal stresses and restore ductility.

  1. Surface protection treatment

Coating protection (recommended)

To avoid reaction with the experimental material or to prevent corrosion, the inner or outer wall can be pre-coated with:

Boron nitride (BN) coating: anti-adhesion, anti-chemical reaction

Alumina (Al ₂ O ₃) spraying: Isolating molten salt and molten metal

Graphite film: suitable for vacuum and high temperature applications

  1. Correct loading and operation

Do not fill the container to the limit, leaving space for thermal expansion;

Avoid direct impact of heavy objects on the inner wall of the crucible;

Minimize the number of handling times to prevent cracks caused by mechanical impact;

Check for cracks, pores or delamination before use. If found, stop using.

  1. Clean up the experimental residue in time

If metal, oxide or molten salt remains in the molybdenum crucible for a long time after use, corrosion or stress concentration will occur;

It is recommended to use mechanical slag removal + organic solvent cleaning + vacuum drying after each experiment.

  1. Avoid contact with active or highly corrosive materials

Sulfur, phosphorus, halogen compounds, perchlorates, nitrates, etc. will corrode or embrittle molybdenum materials;

If it must be used, choose a corrosion-resistant composite crucible or use a protective coating.

======================================================================
