In modern precision welding processes, argon arc welding (TIG welding) is an important welding technology widely used in aerospace, precision manufacturing, chemical equipment, stainless steel processing, and other fields. One of the core components in argon arc welding is the tungsten electrode. Although tungsten electrodes do not melt during welding, they play a crucial role in arc stability, arcing performance, and weld quality. So, what is argon arc welding tungsten electrode? Why is it so critical?
1.Basic definition of argon arc welding tungsten electrode
Argon arc welding tungsten electrode is a type of welding electrode made of tungsten (W) or tungsten alloy, specifically used in TIG (Tungsten Inert Gas) welding processes. Its main function is to create a high-temperature heat source to melt the metal for welding by creating an electric arc between it and the workpiece under the protection of argon gas. Unlike the melted electrode used in manual arc welding, tungsten electrodes do not melt during welding, hence the term “non-melting electrode”.
The core advantages of tungsten electrodes lie in their extremely high melting point (about 3410°C), excellent electrical conductivity, and thermal stability, which enable them to operate stably under high-temperature arcs for long periods of time, forming a concentrated heat source without deformation or ablation.
2.Classification of tungsten electrodes
Tungsten electrodes can be classified into several types based on the different alloying elements in the electrode, including:
Pure tungsten electrode (green): suitable for AC welding, mainly used for aluminum and magnesium alloy welding;
Thorium tungsten electrode (red): It has excellent arcing performance and arc stability, suitable for DC welding, and is widely used in stainless steel and carbon steel.
Cerium tungsten electrode (gray): good performance at low current, easy arcing, suitable for electronic devices and thin plate soldering;
Lanthanum tungsten electrode (black/gold): Considering both DC and AC welding, it is widely suitable for automatic welding;
Zirconium tungsten electrode (white): mainly used for AC welding, suitable for aluminum alloy, the electrode is well spherized;
Rare earth tungsten electrode (purple): combines a variety of rare earth elements, has excellent comprehensive performance, and is suitable for high-end welding equipment.
Each electrode has its range of application and performance characteristics, and choosing the right electrode type is crucial for the stability and efficiency of welding quality.
3.The working principle of tungsten electrode
During TIG welding, a welding power supply directs an electric current to the tungsten electrode and creates a high-temperature arc between the electrode and the workpiece under the coating of an inert shielding gas (usually high-purity argon). The heat generated by this arc is enough to melt the metal, completing the weld. However, the tungsten electrode itself is not involved in the melting process, but its role is to provide a stable and concentrated source of arc emission.
The arcing method can include high-frequency arcing, contact arcing, and boost arcing, and different welding equipment also has different requirements for electrode shape (such as sharpening angle) and arcing method.
4.Sharpening and use skills of tungsten electrode
For a more stable arc and more concentrated heat, tungsten electrodes often require sharpening. Different tip angles affect the shape of the arc, heat distribution, and weld width:
Sharp angles (such as 15°) are suitable for welding thin plates with concentrated arcs;
Blunt angles (such as above 60°) are suitable for thick plates or high-current welding, and the arc is dispersed but more durable.
In addition, electrode contamination, overburning, or sticking should be avoided during the welding process to avoid affecting arc stability or producing “tungsten inclusions”.
5.Application fields and development prospects
Argon arc welding tungsten electrodes are widely used in industries with high welding accuracy requirements, such as:
Aerospace: used for welding light metals such as titanium alloys and aluminum alloys;
Petrochemical: welding stainless steel pipes, pressure vessels;
Medical devices: welding in areas with low heat impact is required;
Electronic manufacturing: suitable for small components and thin plate processing;
Automobile manufacturing: precision welding process for some key components.
With the development of green manufacturing and intelligent welding technology, non-radioactive tungsten electrodes (such as cerium tungsten and lanthanum tungsten) have gradually replaced thorium and tungsten, and the technology of tungsten electrodes is also developing in the direction of high performance, low wear and automatic matching.
