In TIG welding, the fit of the tungsten electrode and the welding wire is crucial for welding quality. Here are the key points for the two to work together:
The Role Of Tungsten Electrodes
As a non-consumable electrode, the tungsten electrode is responsible for generating a stable arc heat source, and the high temperature of the arc makes the welding wire and workpiece melt locally to achieve welding. The tungsten electrode itself is not involved in melting, so it is essential to keep the end sharp and free of contamination.
The Role Of Welding Wire
Welding wire is a filler metal that is melted by arc heating and then supplemented into the weld, determining the chemical composition and mechanical properties of the weld. The material of the welding wire needs to match the base metal to ensure the quality of the weld.
Principle Of Cooperation
Electrode size matches the diameter of the welding wire: Usually the diameter of the tungsten electrode is slightly larger than the diameter of the welding wire to ensure stable arc and sufficient heat.
Welding wire supply method: The welding wire is steadily fed into the welding pool by manual or manipulator, and the speed and angle need to be controlled to avoid arc blowing or welding touching the tungsten electrode.
Protective gas coverage: Argon gas protects the welding area, prevents oxidation of the weld seam and electrode, and ensures welding quality.
Operation skills: The operator needs to coordinate the electrode position, wire feed and welding speed to achieve uniform melting and good weld formation.
Notes:
The welding wire should not be in direct contact with the tungsten electrode to avoid electrode contamination and arc instability.
The electrode tip needs to be properly sharpened to create a stable arc.
The material and specification of the welding wire should be selected according to the base metal and process requirements.
