Keeping tungsten electrodes cool is essential to ensure electrode stability and extend their lifespan during argon arc welding (TIG welding). Here are the commonly used cooling methods and considerations:
Water Cooling System
Many industrial-grade TIG welders are equipped with a water-cooling system that wraps around the electrode carrier through a water-cooled jacket or cooling line to quickly remove heat from the electrode and tip and prevent the electrode from overheating. The water cooling system is suitable for high-current, high-power welding applications.
Air Cooling System
Low-power or portable welding machines are commonly air-cooled. Air is blown through the air supply port towards the electrode bracket and electrodes, helping to dissipate heat. Air cooling is suitable for low-current welding, but the cooling efficiency is not as good as that of water cooling.
Reasonable Selection of Electrode Diameter and Length
Coarser tungsten electrodes have better thermal conductivity, stronger heat resistance, and are not easy to overheat. Properly shortening the electrode length can also help reduce the end temperature and reduce the risk of overheating.
Guaranteed Gas Flow
Shielding gases (such as argon) not only protect the weld area from oxidation, but also take away some of the heat and play a cooling role. The gas flow rate should be kept appropriate to avoid insufficient cooling due to too small.
Operating Tips
Avoid direct contact between the electrode and the workpiece or the melt pool to reduce local overheating of the electrode electrode. Maintain a good shape of the electrode tip and reduce the concentration point of arc energy.
Check And Replace Electrodes Regularly
Timely repair and replace damaged or overheated deformed electrodes to ensure cooling efficiency and welding stability.
